Info / imprint box

The info box opens via the gear → Info / imprint, the command Info / imprint — and automatically at every program start as long as the disclaimer has not been confirmed. In that state the program also loads the sample drawing Default-Drawing from the program folder if present — but only if nothing has happened since the start (nothing drawn, opened or inserted); otherwise it silently stays away.

While the info box is open

No key reaches the drawing while the info box, or the licences window above it, is open; Tab stays within the window. Esc closes the licences first, then the info box. If an add-on tool hands over a part at start, the part waits until the info box is closed and only then hangs at the mouse. If the registration window also appears at start, it lies above the info box; Esc then acts there first.

The info box
The info box

Version

Below the logo: Version 4.0.55 · Build YYYY-MM-DD · #n — the program version, the date of the call, the number of your own program start (local counter cad2d_launchCount) — and, if the server is reachable, 🌍 … users / … launches worldwide. If LiberoDraft was opened with a start link, Licence valid until … with the expiry date appears below it (Registration).

Support LiberoDraft

Link to the donation page of liberodraft.com: LiberoDraft is free, its further development is secured by voluntary donations. Donate now → opens the page in a new tab.

Publisher, locations, contact

Company, subtitle, Since 1985, the two locations, telephone, web, e-mail, commercial register and VAT number. Company, subtitle, locations, telephone, web and e-mail are taken from the file impressum.json next to the program at start — the operator can maintain them without a program update. The same file may provide the address of the online help in the field hilfe. Because impressum.json has no English fields, the subtitle, “Seit 1985” and the locations appear in German in the English interface as well.

Standard parts and library content

The note that supplied and inserted standard parts are non-binding aids and that every standard part must be checked before further use. Context: Standard parts.

Liability notice / disclaimer

The general disclaimer on external links, the currency of the information, trademarks and the use of the software.

Technology

Keywords on the technology: WebGL 2.0 rendering, iterative constraint solver, file formats .cad2d (JSON), .dxf and .svg, analytical hatch boundary detection, persistent dimensioning, snap with eight modes.

Disclaimer understood

Checkbox: Disclaimer understood — do not show this info box automatically at program start anymore. The state is stored locally (cad2d_disclaimerAck, stays on the computer) and reported at once: Disclaimer confirmed — the info box is no longer shown automatically at startup or The info box will be shown again at program start. The box remains available via the gear at any time.

Licenses & copyrights, Close

📜 Licenses & copyrights opens the window Open-source licenses & sources: LiberoDraft is donationware by CADTEC (Schweiz) GmbH, written entirely in its own JavaScript and WebGL, without external scripts, CDN, third-party libraries or bundled font files; the fonts referenced by name only are listed. Close, Esc or a click beside the box closes it.
